Detailed Description

template<typename TOutput, unsigned int VDimension>
class itk::LevelSetSparseImage< TOutput, VDimension >

Base class for the sparse representation of a level-set function on one Image.

Template Parameters

TImage Input image type of the level set function

Todo:: Think about using image iterators instead of GetPixel()

Definition at line 42 of file itkLevelSetSparseImage.h.

Public Types
using	ConstPointer = SmartPointer< const Self >

using	GradientType = typename Superclass::GradientType

using	HessianType = typename Superclass::HessianType

using	InputType = typename Superclass::InputType

using	LabelMapConstPointer = typename LabelMapType::ConstPointer

using	LabelMapPointer = typename LabelMapType::Pointer

using	LabelMapType = LabelMap< LabelObjectType >

using	LabelObjectLengthType = typename LabelObjectType::LengthType

using	LabelObjectLineType = typename LabelObjectType::LineType

using	LabelObjectPointer = typename LabelObjectType::Pointer

using	LabelObjectType = LabelObject< LayerIdType, VDimension >

using	LayerConstIterator = typename LayerType::const_iterator

using	LayerIdListType = std::list< LayerIdType >

using	LayerIdType = int8_t

using	LayerIterator = typename LayerType::iterator

using	LayerMapConstIterator = typename LayerMapType::const_iterator

using	LayerMapIterator = typename LayerMapType::iterator

using	LayerMapType = std::map< LayerIdType, LayerType >

using	LayerType = std::map< InputType, OutputType, Functor::LexicographicCompare >

using	LevelSetDataType = typename Superclass::LevelSetDataType

using	OutputRealType = typename Superclass::OutputRealType

using	OutputType = typename Superclass::OutputType

using	Pointer = SmartPointer< Self >

using	RegionType = typename LabelMapType::RegionType

using	Self = LevelSetSparseImage

using	Superclass = DiscreteLevelSetImage< TOutput, VDimension >

Public Types inherited from itk::DiscreteLevelSetImage< TOutput, VDimension >
using	ConstPointer = SmartPointer< const Self >

using	GradientType = typename Superclass::GradientType

using	HessianType = typename Superclass::HessianType

using	IndexType = Index< VDimension >

using	InputType = typename Superclass::InputType

using	LevelSetDataType = typename Superclass::LevelSetDataType

using	OutputRealType = typename Superclass::OutputRealType

using	OutputType = typename Superclass::OutputType

using	Pointer = SmartPointer< Self >

using	Self = DiscreteLevelSetImage

using	Superclass = LevelSetImage< IndexType, VDimension, TOutput >

Public Types inherited from itk::LevelSetImage< Index< VDimension >, VDimension, TOutput >
using	ConstPointer = SmartPointer< const Self >

using	GradientType = typename Superclass::GradientType

using	HessianType = typename Superclass::HessianType

using	ImageBaseType = ImageBase< VDimension >

using	InputType = typename Superclass::InputType

using	LevelSetDataType = typename Superclass::LevelSetDataType

using	OffsetType = typename ImageBaseType::OffsetType

using	OffsetValueType = typename ImageBaseType::OffsetValueType

using	OutputRealType = typename Superclass::OutputRealType

using	OutputType = typename Superclass::OutputType

using	Pointer = SmartPointer< Self >

using	Self = LevelSetImage

using	Superclass = LevelSetBase< Index< VDimension >, VDimension, TOutput, ImageBaseType >

Public Types inherited from itk::LevelSetBase< Index< VDimension >, VDimension, TOutput, ImageBase< VDimension > >
using	ConstPointer = SmartPointer< const Self >

using	DomainType = ImageBase< VDimension >

using	GradientType = CovariantVector< OutputRealType, VDimension >

using	HessianType = Matrix< OutputRealType, VDimension, VDimension >

using	InputType = Index< VDimension >

using	OutputRealType = typename NumericTraits< OutputType >::RealType

using	OutputType = TOutput

using	Pointer = SmartPointer< Self >

using	RegionType = IdentifierType

using	Self = LevelSetBase

using	Superclass = DataObject

Public Types inherited from itk::DataObject
using	ConstPointer = SmartPointer< const Self >

using	DataObjectIdentifierType = std::string

using	DataObjectPointerArraySizeType = std::vector< Pointer >::size_type

using	Pointer = SmartPointer< Self >

using	Self = DataObject

using	Superclass = Object

Public Types inherited from itk::Object
using	ConstPointer = SmartPointer< const Self >

using	Pointer = SmartPointer< Self >

using	Self = Object

using	Superclass = LightObject

Public Types inherited from itk::LightObject
using	ConstPointer = SmartPointer< const Self >

using	Pointer = SmartPointer< Self >

using	Self = LightObject

Public Member Functions
template<typename TLabel >
LabelObject< TLabel, VDimension >::Pointer	GetAsLabelObject ()

const LayerType &	GetLayer (LayerIdType value) const

LayerType &	GetLayer (LayerIdType value)

virtual const char *	GetNameOfClass () const

void	Graft (const DataObject *data) override

void	SetLayer (LayerIdType value, const LayerType &layer)

virtual LayerIdType	Status (const InputType &inputIndex) const


virtual void	SetLabelMap (LabelMapType *labelMap)

virtual LabelMapType *	GetModifiableLabelMap ()

virtual const LabelMapType *	GetLabelMap () const

Public Member Functions inherited from itk::DiscreteLevelSetImage< TOutput, VDimension >
OutputType	Evaluate (const InputType &inputIndex) const override=0

void	Evaluate (const InputType &inputIndex, LevelSetDataType &data) const override

virtual GradientType	EvaluateBackwardGradient (const InputType &inputIndex) const

void	EvaluateBackwardGradient (const InputType &inputIndex, LevelSetDataType &data) const override

virtual GradientType	EvaluateForwardGradient (const InputType &inputIndex) const

void	EvaluateForwardGradient (const InputType &inputIndex, LevelSetDataType &data) const override

GradientType	EvaluateGradient (const InputType &inputIndex) const override

void	EvaluateGradient (const InputType &inputIndex, LevelSetDataType &data) const override

HessianType	EvaluateHessian (const InputType &inputIndex) const override

void	EvaluateHessian (const InputType &inputIndex, LevelSetDataType &data) const override

OutputRealType	EvaluateLaplacian (const InputType &inputIndex) const override

void	EvaluateLaplacian (const InputType &inputIndex, LevelSetDataType &data) const override

OutputRealType	EvaluateMeanCurvature (const InputType &inputIndex) const override

void	EvaluateMeanCurvature (const InputType &inputIndex, LevelSetDataType &data) const override

Public Member Functions inherited from itk::LevelSetImage< Index< VDimension >, VDimension, TOutput >
virtual OffsetType	GetDomainOffset () const

virtual void	SetDomainOffset (OffsetType _arg)

Public Member Functions inherited from itk::LevelSetBase< Index< VDimension >, VDimension, TOutput, ImageBase< VDimension > >
virtual OutputType	Evaluate (const InputType &iP) const =0

virtual GradientType	EvaluateGradient (const InputType &iP) const =0

virtual OutputRealType	EvaluateGradientNorm (const InputType &iP) const

virtual HessianType	EvaluateHessian (const InputType &iP) const =0

virtual OutputRealType	EvaluateLaplacian (const InputType &iP) const =0

virtual OutputRealType	EvaluateMeanCurvature (const InputType &iP) const =0

virtual void	Evaluate (const InputType &iP, LevelSetDataType &ioData) const =0

virtual void	EvaluateGradient (const InputType &iP, LevelSetDataType &ioData) const =0

virtual void	EvaluateHessian (const InputType &iP, LevelSetDataType &ioData) const =0

virtual void	EvaluateLaplacian (const InputType &iP, LevelSetDataType &ioData) const =0

virtual void	EvaluateGradientNorm (const InputType &iP, LevelSetDataType &ioData) const

virtual void	EvaluateMeanCurvature (const InputType &iP, LevelSetDataType &ioData) const

virtual void	EvaluateForwardGradient (const InputType &iP, LevelSetDataType &ioData) const =0

virtual void	EvaluateBackwardGradient (const InputType &iP, LevelSetDataType &ioData) const =0

virtual bool	IsInside (const InputType &iP) const

virtual RegionType	GetMaximumNumberOfRegions () const

void	Initialize () override

void	UpdateOutputInformation () override

void	SetRequestedRegionToLargestPossibleRegion () override

void	CopyInformation (const DataObject *data) override

void	Graft (const DataObject *data) override

bool	RequestedRegionIsOutsideOfTheBufferedRegion () override

bool	VerifyRequestedRegion () override

void	SetRequestedRegion (const DataObject *data) override

virtual void	SetRequestedRegion (const RegionType &region)

virtual RegionType	GetRequestedRegion () const

virtual void	SetBufferedRegion (const RegionType &region)

virtual RegionType	GetBufferedRegion () const

Public Member Functions inherited from itk::DataObject
virtual void	DataHasBeenGenerated ()

void	DisconnectPipeline ()

bool	GetDataReleased () const

virtual const bool &	GetReleaseDataFlag () const

SmartPointer< ProcessObject >	GetSource () const

DataObjectPointerArraySizeType	GetSourceOutputIndex () const

const DataObjectIdentifierType &	GetSourceOutputName () const

virtual ModifiedTimeType	GetUpdateMTime () const

virtual void	PrepareForNewData ()

virtual void	PropagateRequestedRegion ()

void	ReleaseData ()

virtual void	ReleaseDataFlagOff ()

virtual void	ReleaseDataFlagOn ()

virtual void	ResetPipeline ()

void	SetReleaseDataFlag (bool flag)

bool	ShouldIReleaseData () const

virtual void	Update ()

virtual void	UpdateOutputData ()

void	SetPipelineMTime (ModifiedTimeType time)

virtual const ModifiedTimeType &	GetPipelineMTime () const

virtual void	SetRealTimeStamp (RealTimeStamp _arg)

virtual const RealTimeStamp &	GetRealTimeStamp () const

Public Member Functions inherited from itk::Object
unsigned long	AddObserver (const EventObject &event, Command *)

unsigned long	AddObserver (const EventObject &event, Command *) const

LightObject::Pointer	CreateAnother () const override

virtual void	DebugOff () const

virtual void	DebugOn () const

Command *	GetCommand (unsigned long tag)

bool	GetDebug () const

MetaDataDictionary &	GetMetaDataDictionary ()

const MetaDataDictionary &	GetMetaDataDictionary () const

virtual ModifiedTimeType	GetMTime () const

virtual const TimeStamp &	GetTimeStamp () const

bool	HasObserver (const EventObject &event) const

void	InvokeEvent (const EventObject &)

void	InvokeEvent (const EventObject &) const

virtual void	Modified () const

void	Register () const override

void	RemoveAllObservers ()

void	RemoveObserver (unsigned long tag)

void	SetDebug (bool debugFlag) const

void	SetReferenceCount (int) override

void	UnRegister () const noexceptoverride

void	SetMetaDataDictionary (const MetaDataDictionary &rhs)

void	SetMetaDataDictionary (MetaDataDictionary &&rrhs)

virtual void	SetObjectName (std::string _arg)

virtual const std::string &	GetObjectName () const

Public Member Functions inherited from itk::LightObject
virtual void	Delete ()

virtual int	GetReferenceCount () const

	itkCloneMacro (Self)

void	Print (std::ostream &os, Indent indent=0) const

Static Public Attributes
static constexpr unsigned int	Dimension = Superclass::Dimension

Static Public Attributes inherited from itk::DiscreteLevelSetImage< TOutput, VDimension >
static constexpr unsigned int	Dimension = Superclass::Dimension

Static Public Attributes inherited from itk::LevelSetImage< Index< VDimension >, VDimension, TOutput >
static constexpr unsigned int	Dimension

Static Public Attributes inherited from itk::LevelSetBase< Index< VDimension >, VDimension, TOutput, ImageBase< VDimension > >
static constexpr unsigned int	Dimension

Protected Member Functions
void	CopyInformation (const DataObject *data) override

void	Initialize () override

virtual void	InitializeInternalLabelList ()=0

virtual void	InitializeLayers ()=0

bool	IsInsideDomain (const InputType &inputIndex) const override

	LevelSetSparseImage ()=default

	~LevelSetSparseImage () override=default

Protected Member Functions inherited from itk::DiscreteLevelSetImage< TOutput, VDimension >
	DiscreteLevelSetImage ()=default

	~DiscreteLevelSetImage () override=default

Protected Member Functions inherited from itk::LevelSetImage< Index< VDimension >, VDimension, TOutput >
virtual bool	IsInsideDomain (const InputType &iP) const =0

	LevelSetImage ()

	~LevelSetImage () override=default

Protected Member Functions inherited from itk::LevelSetBase< Index< VDimension >, VDimension, TOutput, ImageBase< VDimension > >
	LevelSetBase ()

	~LevelSetBase () override=default

Protected Member Functions inherited from itk::DataObject
	DataObject ()

void	PrintSelf (std::ostream &os, Indent indent) const override

virtual void	PropagateResetPipeline ()

	~DataObject () override

Protected Member Functions inherited from itk::Object
	Object ()

bool	PrintObservers (std::ostream &os, Indent indent) const

void	PrintSelf (std::ostream &os, Indent indent) const override

virtual void	SetTimeStamp (const TimeStamp &time)

	~Object () override

Protected Member Functions inherited from itk::LightObject
virtual LightObject::Pointer	InternalClone () const

	LightObject ()

virtual void	PrintHeader (std::ostream &os, Indent indent) const

virtual void	PrintTrailer (std::ostream &os, Indent indent) const

virtual	~LightObject ()

Protected Attributes
LayerIdListType	m_InternalLabelList

LabelMapPointer	m_LabelMap

LayerMapType	m_Layers

Protected Attributes inherited from itk::LevelSetImage< Index< VDimension >, VDimension, TOutput >
OffsetType	m_DomainOffset

ScalingType	m_NeighborhoodScales

Protected Attributes inherited from itk::LevelSetBase< Index< VDimension >, VDimension, TOutput, ImageBase< VDimension > >
RegionType	m_MaximumNumberOfRegions

RegionType	m_NumberOfRegions

RegionType	m_RequestedNumberOfRegions

RegionType	m_BufferedRegion

RegionType	m_RequestedRegion

Protected Attributes inherited from itk::LightObject
std::atomic< int >	m_ReferenceCount

Additional Inherited Members
Static Public Member Functions inherited from itk::DataObject
static bool	GetGlobalReleaseDataFlag ()

static void	GlobalReleaseDataFlagOff ()

static void	GlobalReleaseDataFlagOn ()

static void	SetGlobalReleaseDataFlag (bool val)

Static Public Member Functions inherited from itk::Object
static bool	GetGlobalWarningDisplay ()

static void	GlobalWarningDisplayOff ()

static void	GlobalWarningDisplayOn ()

static Pointer	New ()

static void	SetGlobalWarningDisplay (bool flag)

Static Public Member Functions inherited from itk::LightObject
static void	BreakOnError ()

static Pointer	New ()

Protected Types inherited from itk::LevelSetImage< Index< VDimension >, VDimension, TOutput >
using	ScalingType = GradientType
