Detailed Description

template<typename TInput, unsigned int VDimension, typename TOutput>
class itk::LevelSetImage< TInput, VDimension, TOutput >

Abstract class for a level-set function on one Image.

Template Parameters

TOutput	OutputType of the level-set function value
VDimension	Dimension of the underlying Image.

Definition at line 39 of file itkLevelSetImage.h.

Public Types
typedef SmartPointer< const Self >	ConstPointer

typedef Superclass::GradientType	GradientType

typedef Superclass::HessianType	HessianType

typedef ImageBase< VDimension >	ImageBaseType

typedef Superclass::InputType	InputType

typedef Superclass::LevelSetDataType	LevelSetDataType

typedef ImageBaseType::OffsetType	OffsetType

typedef ImageBaseType::OffsetValueType	OffsetValueType

typedef Superclass::OutputRealType	OutputRealType

typedef Superclass::OutputType	OutputType

typedef SmartPointer< Self >	Pointer

typedef LevelSetImage	Self

typedef LevelSetBase< TInput, VDimension, TOutput, ImageBaseType >	Superclass

Public Types inherited from itk::LevelSetBase< TInput, VDimension, TOutput, ImageBase< VDimension > >
typedef SmartPointer< const Self >	ConstPointer

typedef ImageBase< VDimension >	DomainType

typedef CovariantVector < OutputRealType, VDimension >	GradientType

typedef Matrix< OutputRealType, VDimension, VDimension >	HessianType

typedef TInput	InputType

typedef NumericTraits < OutputType >::RealType	OutputRealType

typedef TOutput	OutputType

typedef SmartPointer< Self >	Pointer

typedef IdentifierType	RegionType

typedef LevelSetBase	Self

typedef DataObject	Superclass

Public Member Functions
virtual OffsetType	GetDomainOffset () const

virtual const char *	GetNameOfClass () const

virtual void	SetDomainOffset (OffsetType _arg)

Public Member Functions inherited from itk::LevelSetBase< TInput, VDimension, TOutput, ImageBase< VDimension > >
virtual OutputType	Evaluate (const InputType &iP) const =0

virtual GradientType	EvaluateGradient (const InputType &iP) const =0

virtual OutputRealType	EvaluateGradientNorm (const InputType &iP) const

virtual HessianType	EvaluateHessian (const InputType &iP) const =0

virtual OutputRealType	EvaluateLaplacian (const InputType &iP) const =0

virtual OutputRealType	EvaluateMeanCurvature (const InputType &iP) const =0

virtual void	Evaluate (const InputType &iP, LevelSetDataType &ioData) const =0

virtual void	EvaluateGradient (const InputType &iP, LevelSetDataType &ioData) const =0

virtual void	EvaluateHessian (const InputType &iP, LevelSetDataType &ioData) const =0

virtual void	EvaluateLaplacian (const InputType &iP, LevelSetDataType &ioData) const =0

virtual void	EvaluateGradientNorm (const InputType &iP, LevelSetDataType &ioData) const

virtual void	EvaluateMeanCurvature (const InputType &iP, LevelSetDataType &ioData) const

virtual void	EvaluateForwardGradient (const InputType &iP, LevelSetDataType &ioData) const =0

virtual void	EvaluateBackwardGradient (const InputType &iP, LevelSetDataType &ioData) const =0

virtual bool	IsInside (const InputType &iP) const

virtual RegionType	GetMaximumNumberOfRegions () const

virtual void	Initialize () override

virtual void	UpdateOutputInformation () override

virtual void	SetRequestedRegionToLargestPossibleRegion () override

virtual void	CopyInformation (const DataObject *data) override

virtual void	Graft (const DataObject *data) override

virtual bool	RequestedRegionIsOutsideOfTheBufferedRegion () override

virtual bool	VerifyRequestedRegion () override

virtual void	SetRequestedRegion (const DataObject *data) override

virtual void	SetRequestedRegion (const RegionType &region)

virtual RegionType	GetRequestedRegion () const

virtual void	SetBufferedRegion (const RegionType &region)

virtual RegionType	GetBufferedRegion () const

Static Public Attributes
static const unsigned int	Dimension = Superclass::Dimension

Static Public Attributes inherited from itk::LevelSetBase< TInput, VDimension, TOutput, ImageBase< VDimension > >
static const unsigned int	Dimension

Protected Types
typedef GradientType	ScalingType

Protected Member Functions
virtual bool	IsInsideDomain (const InputType &iP) const =0

	LevelSetImage ()

virtual	~LevelSetImage ()

Protected Member Functions inherited from itk::LevelSetBase< TInput, VDimension, TOutput, ImageBase< VDimension > >
	LevelSetBase ()

virtual	~LevelSetBase ()

Protected Attributes
OffsetType	m_DomainOffset

ScalingType	m_NeighborhoodScales

Protected Attributes inherited from itk::LevelSetBase< TInput, VDimension, TOutput, ImageBase< VDimension > >
RegionType	m_MaximumNumberOfRegions

RegionType	m_NumberOfRegions

RegionType	m_RequestedNumberOfRegions

RegionType	m_BufferedRegion

RegionType	m_RequestedRegion
